Mackie 1402VLZ4 14-channel Mixer

Mackie 1402VLZ4 14-Channel Compact Analog Mixer

The Mackie 1402VLZ4 delivers professional analog sound quality in a compact, rugged design. Featuring Mackie's renowned Onyx microphone preamps, premium components, and versatile routing options, this mixer is ideal for live sound, recording studios, podcasting, broadcasting, houses of worship, and rehearsal spaces.

With 14 channels, 6 high-quality Onyx mic preamps, extensive connectivity, and intuitive controls, the 1402VLZ4 provides exceptional headroom, ultra-low noise, and reliable performance for demanding audio applications.

Features

• 14-channel compact analog mixer
• 6 premium Onyx microphone preamps
• Ultra-wide 60 dB gain range
• 128.5 dB dynamic range
• +22 dBu line input handling
• Extended frequency response
• Ultra-low distortion (less than 0.0007%)
• Improved RF rejection for broadcast applications
• Phantom power for condenser microphones
• 14 high-headroom line inputs with +4/-10 operation control
• 3-band EQ on mono channels
• 75 Hz low-cut filter
• 2 auxiliary sends
• 60 mm long-throw faders
• 2 stereo returns for external effects
• ALT 3/4 stereo bus for flexible routing
• Control Room and Headphone source matrix
• High-resolution 12-segment stereo meters
• Dust-resistant sealed rotary controls
• Rugged steel chassis with powder-coated finish
• Rack-mountable using the optional rack ear kit
• Universal multi-voltage power supply

Specifications

• Mixer Type: Analog
• Channels: 14
• Faders: 13 x 60 mm
• Mic Inputs: 6 x XLR
• Phantom Power: Yes
• Line Inputs: 14
• Main Outputs: 2 x XLR, 2 x 1/4"
• Additional Outputs: Tape Out (RCA), Control Room, ALT Outputs
• Auxiliary Sends: 2
• Channel Inserts: 6
• Headphone Output: 1 x 1/4"
• EQ: 3-band
• Rack Mountable: Yes (optional rack kit)
• Dimensions: 14" W x 12.5" D x 3.2" H
• Weight: 9.5 lbs.
