Overview

The Nord Electro 7 elevates the Electro series with a powerful new Synth Section, dedicated per-section effects and a refined panel design with a high-resolution color display. Combining our latest piano features with the Organ and Rotary Speaker from the acclaimed Nord Organ 3, the Nord Electro 7 offers exceptional versatility in a lightweight, stage-ready instrument.

Highlight Features

General

• New Panel design and new large color display.
• Physical Drawbars on all models.
• Pitch Stick and Modulation Wheel on 73 and HP models.
• HP model - new 73-key Kawai Triple Sensor Hammer Action keybed.
• Expression Pedal Assign, enabling pedal control of Synth Filter and effect parameters.

Organ Section

• B3, B3 Bass, Vox, Farfisa, Soft B3 and Pipe organs from Nord Organ 3.
• Rotary Speaker emulation from the Nord Organ 3.
• 3 mic positions for Rotary Speaker.
• Physical Drawbars with LEDs on all models.

Piano Section

• Compatible with the Nord Piano Library.
• Push Encoder for selecting Category and Sounds.
• Dynamic Compression, Unison, Timbre.

Effects Section

• Dedicated effects per section.
• Rate and Amount for Modulation Effects.
• New Spring reverb.
• New Amps (Brit and Suitcase).
• Global Reverb with per layer Send.

Synth Section

• Samples, Analog waveforms and FM synthesis.
• Push Encoder for selecting Category and Sound.
• Vibrato with adjustable rate, amount and delay.
• Mono, Legato and Glide.
• Unison.
• Low-pass filter with Resonance control.
• FM Partial and FM Amount.
• Dual envelope for Amp and Filter/FM.
• Compatible with the Nord Sample Library.

*All specifications and product images subject to change without further notice.

Specifications

General

• Color display
• Organ, Piano and Synth sound sections
• Seamless Transitions
• Split Point Crossfades
• Pitch Stick and Modulation Wheel on 73 and HP models
• 20 banks with 25 programs - 500 locations
• Live Mode: 5 Live programs
• Selectable split point with LED indication (9 locations)
• Organize for programs
• Global Transpose: +/- 6 semitones
• Global Fine-tune: +/- 50 Cents
• Program Transpose: +/- 6 semitones
• MIDI over USB

Keybed

• Nord Electro 7 HP: 73-key (6 octaves, E-E) Triple sensor Kawai Hammer Action Portable keyboard.
• External keyboard feature (Aux KB).
• Expression Pedal Assign, enabling pedal control of Synth Filter and many effect parameters.

Organ Section

• B3, B3+Bass, Soft B3, Vox, Farfisa and Pipe model with full polyphony.
• B3 Percussion Controls with Poly option.
• Vibrato/Chorus with B3 Deep mode.
• Adjustable percussion level and percussion decay.
• 3 Tonewheel modes: select the level of "vintage" desired.
• 2 Organ manual Presets and Live Drawbars.
• Physical Drawbars with LED indicators.

Piano Section

• Categories: Grand, Upright, Electric, Digital/Layer, Clav/Harpsichord and Misc/Mallet.
• Pianos can be added, replaced and organized using the Nord Sound Manager.
• String Resonance.
• Timbre settings - individually tailored for acoustic, electric and clavinet sounds.
• 3 KB Touch settings.
• Dynamic Compression for even sound level without altering the tonal character.
• Unison with 3 amount options.
• 120 Voices polyphony for Piano Library sounds.

Synth Section

• Sample, Analog and FM synthesis.
• Samples can be added, replaced and organized using the Nord Sound Manager.
• Preset library for Analog and FM sound.
• Amp and Filter/FM ADR/ASR envelopes.
• Velocity and Amount controls for Filter/FM envelope.
• Low Pass Filter with Cutoff and Resonance controls for Analog and Sample sounds.
• Amount and Partial controls for FM.
• Mono, Legato and Glide options.
• Unison with 3 amount options.
• 3 Dynamics/amp velocity options.
• Vibrato with adjustable rate, amount and delay.
• Synth Vibrato button for real time control.
• 30+ voice polyphony.

Rotary Speaker

• Rotary Speaker emulation from Nord Organ 3.
• Close, Wide and XY Mic Position options.
• Bass Wide (stereo) option.
• Dedicated tube Drive control.
• Fix Angle option for Stop position (user adjustable).

Effect Section

• General: Dedicated Effects for Organ, Piano and Synth | FX Focus with FX Bypass option | Expression Pedal can be assigned to most effect parameters.
• Mod 1: Pan1 (Soft), Pan2 (Hard), Tremolo, Wah and Ring Modulator | Dedicated Rate and Amount Controls.
• Mod 2: Phaser, Flanger, Chorus, Vibe and Ensemble | Wide option for stereo width | Dedicated Rate and Amount Controls.
• Equalizer/Amp Simulations: Twin, Small, Suitcase, JC and Brit amp models | Drive | Three band EQ, with sweepable mid. +/- 15 dB gain/attenuation.
• Delay: Tempo with Tap function | Feedback and Dry/Wet controls | Low Pass, High Pass and Band Pass feedback filter options | Ping Pong with 3 amount options | Analog mode | Global mode.
• Compressor: Amount control and Global option.
• Global Reverb: Spring, Room, Stage, Hall and Cathedral reverb types | Spring Reverb placed before Rotary Speaker | Chorale option for all reverb types | Bright/Dark options | Dry/Wet control with Layer Send mode for individual control of reverb level per section.

Connections

• 2 Audio outputs L & R - ¼", 6,35 mm jacks, unbalanced
• 1 Monitor input - 1/8", 3,5 mm stereo jack
• 1 Headphone output - ¼", 6,35 mm stereo jack
• 1 Expression pedal input - ¼", 6,35 mm TRS stereo jack
• Sustain Pedal - ¼", 6,35 mm jack. Compatible with Nord Sustain Pedal 2 (continuous sensor), Nord Triple Pedal 1 and switch type pedals
• Rotary Control/Foot Switch - ¼", 6,35 mm jack. Use a momentary pedal or a switch type pedal.
• MIDI In & Out - 5 pin DIN connectors
• USB - type B connector for USB MIDI, Software Update and Sound Transfer
• Power Cord with IEC C14 connector

Dimensions, Weight & Accessories

• Dimensions: 1066 mm (42.1") W x 104 mm (4.1") H x 341 mm (13.4") D
• Weight: 9.5 kg (20.9 lbs)
• Included Accessories: User Manual, Power cord
