ONE-PIECE BOLT-ON MAPLE NECK WITH GRAPHITE REINFORCEMENT AND SCARF JOINT
A type of neck constructed with a scarf joint for an angled back headstock, which in turn increases the tension behind the nut eliminating the need for string trees and/or string retainer bars. The bolt-on neck joins the neck to the body of the guitar with screws or bolts, allowing for more control, attack and sustain.
- GENERAL
MODEL NUMBER 2911138522 SERIES JS COLOR Bright Blue NUMBER OF STRINGS 6 ORIENTATION Left-Hand
- BODY
BODY FINISH Gloss BODY SHAPE Dinky™ BODY MATERIAL Poplar
- MISCELLANEOUS
STRINGS NPS, .009-.042 Gauges
- NECK
NECK CONSTRUCTION 1 Piece Maple NECK FINISH Satin NECK BINDING White SCALE LENGTH 25.5" (648 mm) FINGERBOARD RADIUS 12"-16" Compound Radius (304.8 mm to 406.4 mm) FINGERBOARD MATERIAL Amaranth NUMBER OF FRETS 24 FRET SIZE Jumbo NUT WIDTH 1.625" (41.3 mm) POSITION INLAYS Pearloid Sharkfin TRUSS ROD NUT Truss Rod Adjustment at Nut HEADSTOCK Jackson® Pointed 6-In-Line NECK PLATE Jackson®
12"-16" COMPOUND RADIUS FINGERBOARD
Jackson pioneered the use of the innovative 12"-16" compound radius design, in which the fingerboard gradually flattens toward the heel from its more rounded profile at the nut. This makes for comfortable and natural-feeling chording and riffing near the nut, with optimal shred articulation and bending nearer the heel.
- HARDWARE
BRIDGE Floyd Rose® Licensed Jackson® Double-Locking Tremolo HARDWARE FINISH Black TUNING MACHINES Jackson® Sealed Die-Cast PICKGUARD None PICKUP COVERS Black CONTROL KNOBS Dome-Style SWITCH TIP Black
- ELECTRONICS
BRIDGE PICKUP Jackson® High-Output Humbucking NECK PICKUP Jackson® High-Output Humbucking CONTROLS Master Volume, Master Tone PICKUP SWITCHING 3-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup CONFIGURATION HH
