HSS CONFIGURATION: DUNCAN DESIGNED™ HB-103B/DUNCAN DESIGNED™ HR-101 HOT RAILS™ PICKUPS
An atypical configuration for Jackson, this guitar features a humbucker in the bridge position and two Hot-Rails™ pickups in the neck and mid positions. The powerful Duncan Designed HB-103B delivers high output tone with lots of crunch and harmonics, while the fearsome Duncan Designed™ HR-101 Hot Rails™ deliver warm and articulate chords, with a scoop in the mids, solos will be fat and crisp with near-endless sustain.
- GENERAL
MODEL NUMBER 2916342544 SERIES X Series COLOR Satin Graphite NUMBER OF STRINGS 6 ORIENTATION Right-Hand
- BODY
BODY FINISH Satin BODY SHAPE Soloist BODY MATERIAL Basswood
- MISCELLANEOUS
STRINGS NPS, .009-.042 Gauges
- NECK
NECK CONSTRUCTION Maple NECK FINISH Satin NECK BINDING White SCALE LENGTH 25.5" (648 mm) FINGERBOARD RADIUS 12"-16" Compound Radius (304.8 mm to 406.4 mm) FINGERBOARD MATERIAL Rosewood NUMBER OF FRETS 24 FRET SIZE Jumbo NUT WIDTH 1.6875" (42.86 mm) POSITION INLAYS Pearloid Sharkfin TRUSS ROD NUT Truss Rod Adjustment at Nut HEADSTOCK Jackson® Pointed 6-In-Line NECK PLATE None
FLOYD ROSE® SPECIAL DOUBLE-LOCKING TREMOLO (RECESSED)
Recessed for picking-hand comfort, the Floyd Rose Special double-locking tremolo features zinc alloy saddles and a zinc alloy sustain block. The double-locking design allows you to lock your guitar in tune at the nut and at the bridge, resulting in excellent tuning stability and sustain throughout your most aggressive pull-ups and dive bombs.
- HARDWARE
BRIDGE Floyd Rose® Special Double-Locking Tremolo (Recessed) HARDWARE FINISH Black TUNING MACHINES Jackson® Sealed Die-Cast PICKGUARD None PICKUP COVERS Black CONTROL KNOBS Dome-Style SWITCH TIP Black
- ELECTRONICS
BRIDGE PICKUP Duncan Designed™ HB-103 MIDDLE PICKUP Duncan Designed™ HR-101 Hot Rails™ NECK PICKUP Duncan Designed™ HR-101 Hot Rails™ CONTROLS Volume, Tone PICKUP SWITCHING 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup CONFIGURATION HSS
