BLX288/SM58 with SM58 Capsules (H11: 572 to 596 MHz)
Overview
The Shure BLX288/SM58 Wireless Dual Vocal System combines professional-quality sound with simple setup and up to 14 hours battery life for legendary audio performance for two vocalists right out of the box. The system includes BLX88 tabletop dual-channel receiver, 2 legendary SM58 handheld transmitters, 2 microphone clips, power supply, 2 AA batteries, and user guide.
Specs
System
| Wireless Technology |
Analog UHF |
| Diversity |
Yes |
| RF Frequency Band |
H11: 572 to 596 MHz |
| Number of RF Channel Frequencies |
123 |
| Max Operating Range |
300' / 91.4 m (Line of Sight) |
| Max Transmitters per Band |
12 |
| Dynamic Range |
100 dBA |
| Encryption |
No |
| Built-In Recorder |
No |
| Timecode Support |
No |
| Mobile App Compatible |
No |
Receiver
| Receiver Type |
1x Tabletop |
| Mounting Options |
No |
| Antenna |
2x Internal |
| Number of Audio Channels |
2 |
| Audio I/O |
2x XLR 3-Pin Balanced Output
2x 1/4" TS Unbalanced Output |
| Network I/O |
No |
| USB/Lightning Connectivity |
No |
| Frequency Response |
50 Hz to 15 kHz (Dependent on Mic) |
| Display |
Alphanumeric LED |
| Power Requirements |
AC/DC Power Adapter |
Transmitters
| Included Transmitters |
2x Handheld |
| RF Output Power |
10 mW |
| Antenna |
Internal |
| Input Level |
Microphone |
| Audio I/O |
No |
| USB I/O |
No |
| Muting |
Off/On Switch |
| Gain Range |
-20 to -10 dB |
| Auto-Level/Gain |
No |
| Sync Method |
Manual |
| Display |
Alphanumeric LED (In Battery Compartment) |
Microphones
| Microphone Type |
1x Handheld with Interchangeable Capsule (SM58 Included) |
| Polar Pattern |
Cardioid |
| Frequency Response |
50 Hz to 15 kHz |
| Maximum SPL |
146 dB |
| Sensitivity |
-54.5 dBV/Pa |
| Color |
Silver / Black |
Power
| Transmitter Battery Type |
2x AA (Included) |
| Transmitter Battery Life |
14 Hours (Alkaline) |
| Included Charging Case |
No |
| AC/DC Power Adapter |
12 to 15 VDC at 160 mA, Center-Positive (Included) |
Physical
| Environmental Resistance |
No |
| Housing |
ABS |
| Dimensions |
Receiver: 15.3 x 4.6 x 1.6" / 388 x 116 x 40 mm
Transmitter: 8.8 x 2.1" / 224 x 53 mm |
| Weight |
Receiver: 15.1 oz / 429 g
Transmitter: 7.7 oz / 218 g (without Batteries) |
