Zoom R24 Multitrack Recorder Controller/Sampler

R24 Multitrack Recorder/Interface/Controller/Sampler Specifications:

• Physical Tracks: 24
• Simultaneous Recording Tracks: 8
• Simultaneous Playback Tracks: 24
• Recording Data Format: 44.1/48kHz, 16/24-bit WAV
• Maximum Recordable Time: 200 minutes / GB (44.1kHz 16-bit, mono tracks)
• Projects: 1,000
• Markers: 100 / Project
• Locator: Hours / Min. / Sec. / msec or Bars / Beats / Ticks
• File Editing: Divide, Trim
• Other Functions: Punch-In / Out (Manual, Automatic), Bounce, A-B Repeat, Undo / Redo, Metronome

• Input Channels: 8
• Output Channels: 2
• Quantization: 24-bit
• Sampling Frequency: 44.1kHz, 48kHz, 88.2kHz, 96kHz

• Faders: 9
• Level Meters: 4-Segment LED
• Track Parameters: 3-Band Equalizer, Pan (Balance), Effect Send x 2, Invert Stereo Links Track pairs: 1/2 to 23/24 selectable

• Algorithms: 9 (CLEAN, DISTORTION, ACO / BASS SIM, BASS, MIC, DUAL MIC, STEREO, 8 x COMP EQ, MASTERING)
• Types: 150 Modules: 7 for Insert, 2 for Send / Return
• Patches: 330 for Insert, 60 for Send / Return
• Tuner: Chromatic, Guitar, Bass, Open A/D/E/G, D modal

• Playback Data Format: 44.1/48kHz, 16/24bit WAV
• Voices: 24
• Editing Functions: Trim, Time-stretch

• Voices: 8
• Sound Format: 16-bit Linear PCM
• Drum Kits: 10
• Pads: 8 (velocity-sensitive)
• Precision: 48 PPQN
• Rhythm Patterns: 511/project
• Patterns: 511 (472 factory, 39 blank) / Project
• Beat: 1/4 - 8/4
• Tempo: 40.0 - 250.0 BPM

• A/D Conversion: 96kHz 24-bit delta-sigma ADC
• D/A Conversion: 96kHz 24bit delta-sigma DAC
• Display: 128 x 64 pixel LCD (with backlight)
• Inputs: 8 x XLR-1/4''Phone Combo Jack / Input Impedance: (Balanced input) 1kÎ balanced, 2nd hot, (Unbalanced input) 50kÎ unbalanced, (Hi-Z Input) 470kÎ / Input Level: -50dBm to +4dBm continuously variable Built-in microphones: Omnidirectional condenser microphones Gain: -50dBm to +4dBm continuously variable
• Phantom Power Supply: 48V / 24V
• Master Output: 1/4" TRS Phone (balanced) / Output Impedance: 1kÎ / Rated Output Level: +4dBm
• Headphones Output: 1/4''Stereo Phone Jack, 20mW x 2 (at 32Î load)
• USB: [B type (USB2.0 High-Speed compatible)] Audio Interface / Control Surface or Mass Storage Class operation [A type (USB2.0 High-Speed compatible)] USB Host capability
• Power Requirements: AC adaptor (DC5V/1A/center positive) or AA size (LR6) battery x6
• Battery Life: 4.5hrs. (with backlight on and phantom power off)Dimensions (WxdxH): 376 x 237.1 x 52.2mm
• Weight: 1.3kg (without batteries)

• Windows XP SP2 or later / Vista SP1 or later / 7
• Intel Pentium 4 1.8GHz or better
• 1GB RAM or more
• USB 2.0 compatible port

• OS X 10.4.11 or later / 10.5 / 10.6
• Intel Core Duo processor 1.83GHz or better
• 1GB RAM or more
• USB 2.0 compatible port.
