Mackie PROFX16V3 16-Channel 4-Bus Professional Effects Mixer with USB
Mackie PROFX16V3 16-Channel 4-Bus Professional Effects Mixer with USB
Mackie PROFX16V3 16-Channel 4-Bus Professional Effects Mixer with USB

Mackie PROFX16V3 16-Channel 4-Bus Professional Effects Mixer with USB

Mackie
SKU: 2051302-00
Sale price$549.99 USD Regular price$649.99 USD

Experience the best-in-class series of professional analog USB mixers with effects. The Mackie ProFX16v3 is a 16-channel mixer that brings next-level performance and versatility to recording studios and venues.

MORE PRO. MORE AWESOME.

Power your studio or live rig with award-winning Onyx preamps and a high-resolution GigFX engine. The Mackie ProFX16v3 gives you ultimate control, versatility and flexibility for multiple applications that range from studio recording to live sound reinforcement. And with the included Waveform OEM software bundle, you’ll have the ultimate plugin collection for fine-tuning your sound.

FEATURES:

  • 16-channel USB mixer with 11 low-noise, high-headroom Onyx preamps that provide 60dB of gain
  • 3-band EQ with On/Off hard bypass switch and variable mid frequency control
  • Dual stereo USB return for additional routing flexibility during performances
  • Latency-free direct monitoring for hassle-free overdub sessions
  • High-resolution recording with sample rates up to 192kHz to Mac/PC via USB
  • 24 included effects, including reverbs, delays and choruses, delivered via GigFX effects engine
  • Built-in compression keeps louder audio in check while pulling up softer audio sources
  • Switchable Hi-Z inputs for guitars, bass, and other instruments
  • 100Hz low-cut filter and 48V phantom power on all channels
  • Aux/Monitor with dedicated per-channel send control
  • Dual stereo subgroup output bus with per-channel assignment
  • Headphone output with separate level and blend control
  • Dedicated control room output with level control
  • Footswitch input for FX mute
  • Waveform OEM professional software bundle included with purchase of ProFX16v3

SPECS:

  • Type: Analog Mixer with USB Interface
  • Channels: 16 (8 x mono, 4 x stereo)
  • Computer Connectivity: USB (2 x 4)
  • A/D Resolution: 24-bit/192kHz
  • Faders: 16 x 60mm Faders
  • Inputs - Mic Preamps: 2 x XLR-1/4" combo (mic/line/Hi-Z), 9 x XLR (mic)
  • Phantom Power: Yes
  • Inputs - Line: 6 x 1/4", 6 x 1/4" (3 x stereo), 1 x 1/8" (stereo)
  • Outputs - Main: 2 x XLR, 2 x 1/4" (L/R), 2 x 1/4" (control room)
  • Outputs - Other: 4 x 1/4" (subgroup out)
  • Aux Sends: 1 x FX Send (post), 2 x Monitor Send (pre), 1 x Monitor Send (pre/post)
  • Send/Return I/O: 1 x 1/4" (FX send), 3 x 1/4" (monitor send)
  • Busses/Groups: 2 x Subgroup
  • Inserts: 8 x 1/4" (channel)
  • Headphones: 1 x 1/4"
  • USB: 1 x Type B
  • Other I/O: 1 x 1/4" (footswitch)
  • EQ Bands: 3-band EQ with Variable Mid Frequency (mic channels), 100Hz Low-cut Filter
  • Signal Processing: 8 x Channel Compressors
  • Effects: GigFX Engine: Reverbs, Chorus, Delay, Flange, Auto-Wah
  • Software: Waveform OEM DAW, FX Plug-in Collection
  • Power Source: Standard IEC AC cable
  • Height: 4.4"
  • Width: 17.7"
  • Depth: 17.1"
  • Weight: 15.2 lbs.
