General Features
- 15" powered loudspeaker with 1100W Class-D amplifier
- Achieves high SPL output with remarkable clarity throughout its frequency response
- 1.75" neodymium high-frequency compression driver and high-output 15" woofer which combine for a wide frequency response with powerful bass
- Frequency Range: 49 Hz to 20 kHz
- Max SPL: 134 dB
- Precision 48-bit DSP processing for clear high-definition sound and built-in D-Contour intelligent dynamic control
- Durable and compact ABS enclosure
- Symmetrical Design for mirror-mode floor monitoring
Key Features
- FIR-X tuning
- Proprietary sound-processing technology utilizing a linear-phase FIR filter delivers high-quality sound at high resolution with a smooth frequency response that is unaffected by phase interference near the crossover point
- D-CONTOUR (Dynamic CONTOUR)
- D-CONTOUR is a multiband compressor that dynamically controls the level of each frequency range according to the application and human hearing characteristics
- FOH/MAIN: For use as a main speaker
- MONITOR: Optimized for use as a floor monitor
- D-CONTOUR is a multiband compressor that dynamically controls the level of each frequency range according to the application and human hearing characteristics
- Mixing/LINK functionality
- Features mixing functionality, enabling you to mix sounds by directly inputting three channel signals into the unit
- LINK function enables you to easily configure a stereo or dual-mono SR (Sound Reinforcement) system using two DXR mkIIs
- DSP-controlled advanced protection system
- Powerful protection circuits ensure secure protection in the speaker unit, amplifier unit, and power supply unit
- Protection functionality promotes optimal performance of each component and optimum reliability without distortion even in challenging environments
