Elevate Expression Everywhere

Built for working musicians, the MODX M Series of synthesizers combines expressive control, streamlined workflow, and exceptional sound in a lightweight design ideal for stage or studio. Featuring three engines that create a stunning variety of sounds, and shared DNA from our flagship MONTAGE M, MODX M elevates expression everywhere.

Video Overview

Sound Features

AN-X Engine

Integrated into the Motion Control system, the AN-X Engine allows you to create expressive, unique analog sounds. It includes:

• Two filters (10 filter types)
• Pulse width modulation & Oscillator Self Sync
• Ring modulation, FM, and wave shaper
• Wave folder
• Voltage drift and aging settings to simulate vintage synth behavior

AWM2

Experience realism and detail with the MODX M Advanced Wave Memory (AWM2). Offering up to 128 Elements per Part, AWM2 allows for more layers and articulations, giving you an expansive canvas for sound creation, especially for “nameable” sounds such as piano and strings.

268 Notes Total Polyphony

MODX M offers up to 268 notes of polyphony across its three engines:

• 128 notes for AWM2 Preset and User Waveform Parts
• 128 notes for FM-X Parts
• 12 notes for AN-X Parts

Additional Sound Features

• Preset Wave and Flash Memory Upgrade: Offers approx. 2x the memory over MODX/MODX+ with an increase from 5.68 GB to 10.7 GB of AWM2 memory, and 1.9 GB of User flash memory.
• VCM Rotary Speaker: Simulates the rich and enveloping motion of a classic rotary speaker cabinet.

Control Features

Dedicated Part and Scene Control

You’ll find dedicated Part and Scene Selection buttons to control 8 Parts per Performance. Particularly beneficial for live performances, this intuitive control improves overall usability and adds dimension to each Performance.

High Resolution Control

The MODX M Knobs, Super Knob, Pitch Bend, Mod Wheel, and Sound Engine are now High Resolution. Because of the fine resolution, you’ll find the MODX M performs smoother than its predecessors.

Motion Control Synthesis Engine

Experience a new level of sound design with this groundbreaking engine using powerful tools such as:

• Motion Sequences: Dynamically automate synth and effect parameters, all perfectly in sync with your tempo.
• Super Knob: Control dozens of modulations with a single gesture.
• Envelope Follower: Shape your sound using input from the A/D or another Part.

Additional Control Features

• 8 Faders, 4 Knobs
• 4 Pedal Inputs
• 6 Display Knobs

Workflow Features

Expanded Softsynth Plugin (ESP) – Available Early 2026

Free for all registered MODX M owners, the Expanded Softsynth Plugin (ESP) replicates MODX M in your favorite Digital Audio Workstation (DAW). ESP lets you create, edit and mix performances anywhere you happen to be – without the hardware – offering an unprecedented level of stage and studio integration.

• Expanded Softsynth Plugin for MODX M
• Download Install Guide

Faster, More Intuitive Navigation

Upgraded navigation enables quick, intuitive sound editing and operation. You’ll find features like a 7" color touch screen, 6 display knobs, and Stereo A/D input with 2 insertion effects.

USB MIDI 2.0 and Multichannel Audio Interface

Simplifying your studio setup, MODX M offers a USB MIDI and multichannel 10 output/4 input audio interface at 44.1kHz. Streamline MIDI recording, virtual instrument monitoring, and multi-track audio recording through a single USB cable. MIDI 2.0 delivers high-resolution data for note velocity, Super Knob, pitch bend, and modulation.

Cubase AI

Cubase AI provides the basic tools for recording, editing and mixing. It’s the perfect entry into the world of Digital Audio Workstations (DAW), offering powerful, yet easy-to-use software tools for all genres.

Dedicated DAW Remote

Use your MODX M as a dedicated hardware controller for DAWs such as Cubase, Logic, ProTools and Live. Control the mixer, transport, Softsynth plugins and more.

Specifications

Model Differences

• MODX M8: 88-Key GHS Keyboard | 51-9/16" x 5-15/16" x 15-3/8" (1,310 x 152 x 391 mm) | 29 lb, 15 oz (13.6 kg)
• MODX M7: 76-Key Semi-weighted FSB Keyboard | 42-7/8" x 4-5/8" x 13-11/16" (1,089 x 117 x 347 mm) | 16 lb, 12 oz (7.6 kg)

Shared Specifications

• Initial Touch / Aftertouch: Yes / No
• Tone Generator: Motion Control Synthesis Engine (AMW2: 128 Elements max | FM-X: 8 Operators, 88 Algorithms | AN-X: 3 Oscillators, 1 Noise)
• Maximum Polyphony: AWM2: 128 (stereo/mono) | FM-X: 128 | AN-X: 12
• Multi Timbral Capacity: 16 Parts (internal), Audio Input Parts (A/D, USB)
• Wave Memory: Preset: 11.29 GB | User: 1.9 GB
• Performance: 3,487
• Filter: 18 types
• Effects: Reverb x 13 types, Variation x 91 types, Insertion A x 91 types, Insertion B x 94 types, Master Effect x 28 types, Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)
• Note Capacity: Approx. 130,000 notes per Song/Pattern
• Note Resolution: 480 ppq (parts per quarter note) | Tempo: 5 – 300 BPM
• Sequencer: 16 Sequence tracks, Tempo track, Scene track | 128 songs | 128 patterns
• Arpeggio: 8 Parts simultaneous (max), Preset: 10,922 types, User: 256 types
• Display: 7" TFT Color Wide VGA LCD touch screen
• Power Consumption: 19 W (using PA-300C AC adaptor)
• Connectors: USB [TO DEVICE/HOST], MIDI [IN/OUT], FOOT CONTROLLER [1/2], FOOT SWITCH [SUSTAIN/ASSIGNABLE], OUTPUT [L/MONO]/[R], [PHONES], A/D INPUT [L/MONO]/[R]
