Overview

For more than a decade, the Pacifica 100 Series has served as an entry-point into the world of electric guitar for budding artists around the globe. Pacifica Series guitars are highly regarded for successfully delivering outstanding tone and comfortable playability, all at an affordable price point.

Key Features

• Alder Body with Gloss Polyurethane Finish
• Bolt-On Maple Neck with Rosewood Fingerboard
• Alnico V Pickups Deliver Warm, Clear Tone
• H/S/S Pickup Configuration with 5-Position Selector
• Push-Pull, Coil-Split Switch for Additional Tonal Options
• Vintage-Style Vibrato Bridge with Block Saddles

Specifications

General

• Construction: Bolt-on
• Scale Length: 25-1/2" (648.0 mm)

Body

• Body Material: Alder
• Body Finish: Gloss Polyurethane

Neck

• Neck Material: Maple
• Neck Finish: Satin Polyurethane
• Fingerboard Material: Rosewood
• Fingerboard Radius: 13-3/4" (350 mm)
• Fret Wire: Medium
• Number of Frets: 22
• Nut Material: Urea
• Neck Width @ 0 Fret / 12th Fret: 41.0 / 51.4 mm
• Thickness @ 1st Fret / 12th Fret: 20.9 / 22.9 mm

Electronics

• Neck Pickup: Single Coil / Alnico V
• Middle Pickup: Single Coil / Alnico V
• Bridge Pickup: Humbucker / Alnico V
• Controls: Master Volume, Master Tone (Push-Pull Coil Split)
• Pickup Switch: 5-Position Lever Switch

Hardware

• Bridge: Vintage Style Tremolo with Block Saddle
• Tremolo Arm: Φ5 (Screw-in)
• String Spacing: 10.5 mm
• Tuning Machines: Die-Cast
• Pickguard: 3-Ply White

Miscellaneous

• String Gauge: D'Addario EXL120 / 0.009-0.042
